Wavelength Calibration Sources

Khác HF Corp

Overview



Spectrometer wavelength calibration sources are available for convenient, reliable spectrometer calibration across UV-NIR wavelengths.

Options include mercury-argon (253-1700 nm), krypton (427-893 nm), neon (540-754 nm), argon (696-1704 nm) and xenon (916-1984 nm) gas-discharge emission sources. With multiple wavelength options and emission lines to utilize, users can more readily choose a source, or combination of sources, to match analytical wavelengths of interest within the measurement range.





  • Gas-discharge sources — produce atomic emission lines for performing reliable spectrometer wavelength calibration
  • UV-NIR coverage — choose from multiple sources across a broad range of wavelengths
  • Remote on/off operation -- helps you avoid disturbing experiment setups
  • Convenient power features — sources include 5 VDC power supply and embedded, rechargeable lithium ion battery







Engineering

Source: Argon, Krypton, Mercury Argon, Xenon

Wavelength Range: 253nm - 1.984μm

Amplitude Stabilization: ~1 minute

Source Lifetime: 3,500 hours (typical)



Physical

Fiber Connector: SMA 905

Aperture: 3 mm

Dimensions: 16.7 x 10.6 x 3.4 cm (without feet)

Power Consumption: 2A (maximum) at 5 VDC when battery is charging

Power Requirements: 5 VDC power supply; rechargeable, embedded lithium ion battery

Weight: 180 g







  AR-2 HG-2 KR-2 NE-2 XE-2
Source Argon Mercury Argon Krypton Neon Xenon
Wavelength Range 696nm - 1.704μm 253nm - 923nm

427nm - 893nm

540nm - 754nm 916nm - 1.984μm
Fiber Connector SMA 905

SMA 905

SMA 905 SMA 905

SMA 905

Power Requirements

5 VDC power supply; rechargeable, embedded lithium ion battery

5 VDC power supply; rechargeable, embedded lithium ion battery

5 VDC power supply; rechargeable, embedded lithium ion battery

5 VDC power supply; rechargeable, embedded lithium ion battery

5 VDC power supply; rechargeable, embedded lithium ion battery
