Engineering
|
Nominal Bulb Power
|
4.75 W
|
|
Source
|
Long Lifetime Tungsten Halogen
|
|
Typical Output Power
|
4.5 mW
|
|
Wavelength Range
|
360nm - 2.4μm
|
|
Color Temperature
|
2,800 K
|
|
Drift of Optical Output
|
<0.1% per hour
|
|
Pulse Power
|
2,800 K
|
|
Source Lifetime
|
1000 hours (typical)
10000 hours (typical)
2000 hours tungsten
45000 hours LEDs
|
|
Stability of Light Source Output
|
0.25% peak-to-peak
|
|
Warm-up Time
|
10 minutes
|
Environmental
|
Safety & Regulatory
|
CE, ROHS, WEEE
|
|
Operating Humidity Specification
|
5-95% without condensation at 40 °C
|
|
Operating Temperature
|
5 °C – 35 °C
|
Physical
|
Fiber Connector
|
SMA 905
|
|
Shutter
|
No, Yes
|
|
Cuvette Pathlength
|
10 mm
|
|
Dimensions
|
58 x 59 x 140 mm
58 x 59 x 140mm
88.9 x 35.6 x 34.4 mm (with feet)
|
|
Integrated Cuvette Holder
|
No, Yes
|
|
Integrated Filter Holder
|
No, Yes
|
|
Power Consumption
|
up to 15 W
up to 30 W
|
|
Power Requirements
|
12 VDC, 24 VDC, 5V DC
powered via Flame spectrometer over USB
|
|
Trigger/Shutter Input Connection
|
SUB-D-15 pin
|
|
Trigger/Shutter Input Signal
|
TTL; Up to 2.5 Hz maximum
|
|
Weight
|
180 g - 0.5 kg
|
If you click the product's name, you can go to that product's page.
| |
HL-2000-FHSA-LL |
HL-2000-LL |
HL-2000-HP |
HL-2000-HP-FHSA |
FLAME-DA-CUV-VIS-NIR |
| Wavelength Range |
360nm - 2.4μm |
360nm - 2.4μm |
360nm - 2.4μm |
360nm - 2.4μm |
390nm - 900nm |
| Source |
Long Lifetime Tungsten Halogen |
Long Lifetime Tungsten Halogen |
High-powered Tungsten Halogen |
High-powered Tungsten Halogen |
Tungsten-Halogen with a violet LED |
| Source Lifetime |
1000 hours (typical) |
10,000 hours (typical) |
1000 hours (typical) |
1000 hours (typical) |
2000 hours tungsten
45000 hours LEDs |
| Nominal Bulb Power |
4.75 W |
4.75 W |
20 W |
20 W (tungsten halogen) |
— |
| Typical Output Power |
4.5 mW |
4.7 mW |
8.8 mW |
8.4 mW |
— |
| Safety & Regulatory |
CE
ROHS
WEEE |
CE
ROHS
WEEE |
CE
ROHS
WEEE |
CE
ROHS
WEEE |
— |
| Shutter |
Yes |
No |
No |
Yes |
— |
| Fiber Connector |
SMA 905 |
SMA 905 |
SMA 905 |
SMA 905 |
— |
| Cuvette Pathlength |
— |
— |
— |
— |
10 mm |
| Dimensions |
58 x 59 x 140 mm |
58 x 59 x 140 mm |
58 x 59 x 140 mm |
58 x 59 x 140 mm |
88.9 x 35.6 x 34.4 mm (with feet) |
| Integrated Filter Holder |
YES |
NO |
NO |
YES |
No |
| Weight |
0.5 kg |
0.5 kg |
0.5 kg
|
0.5 kg |
180 g |
| Integrated Cuvette Holder |
NO |
NO |
NO |
NO |
Yes |
| Power Requirements |
24 VDC |
12 VDC |
24 VDC |
24 VDC |
5V DC
powered via Flame spectrometer over USB |
| Warm up Time |
10 minutes |
10 minutes |
10 minutes |
10 minutes |
|
| Operating Temperature |
5 °C – 35 °C |
5 °C – 35 °C |
5 °C – 35 °C |
5 °C – 35 °C |
|
