Vis-NIR光源

Overview

ｸﾘﾌﾟﾄﾝ及びﾀﾝｸﾞｽﾃﾝﾊﾛｹﾞﾝ光源は､360〜2500nmの測定に使用できます｡これらの白色光(広帯域幅)ｵﾌﾟｼｮﾝは､吸光度､色､反射率に最適です｡

	Krypton Light Source	Tungsten Halogen Light Sources
Nominal Bulb Power	1.3 W	20 W (tungsten halogen), 4.75 W
Source	Krypton Halogen	High-powered Tungsten Halogen, Long Lifetime Tungsten Halogen, Tungsten-Halogen with a violet LED
Typical Output Power	3.07 mW	4.5 mW, 4.7 mW, 8.4 mW, 8.8 mW
Wavelength Range	400nm - 2.5μm	360nm - 2.4μm
Drift of Optical Output	< 0.5 % per hour	<0.3% per hour
Pulse Power	2,800 K	2,800 K
Source Lifetime	2,000 hours (typical)	1,000 hours (typical), 10,000 hours (typical), 2,000 hours tungsten; 45,000 hours LEDs
Stability of Light Source Output	0.06% peak-to-peak	0.15% peak-to-peak, 0.25% peak-to-peak
Warm-up Time	10 minutes	10 minutes
Shutter	NO	NO, YES
Cuvette Pathlength	10 mm	10 mm
Dimensions	9.5 cm x 5 cm	6.2 x 6 x 15 cm, 88.9 x 35.6 x 34.4 mm (with feet)

	HL-2000-FHSA-LL	HL-2000-LL	HL-2000-HP	HL-2000-HP-FHSA	FLAME-DA-CUV -VIS-NIR
Nominal Bulb Power	4.75 W	4.75 W	20 W	20 W (tungsten halogen)
Source	Long Lifetime Tungsten Halogen	Long Lifetime Tungsten Halogen	High-powered Tungsten Halogen	High-powered Tungsten Halogen	Tungsten-Halogen with a violet LED
Typical Output Power	4.5 mW	4.7 mW	8.8 mW	8.4 mW
Wavelength Range:	360nm - 2.4μm	360nm - 2.4μm	360nm - 2.4μm	360nm - 2.4μm	390nm - 900nm
Fiber Connector:	SMA 905	SMA 905	SMA 905	SMA 905
Integrated Cuvette Holde	No	No	No	No	Yes
Power Requirements		12 VDC	24 VDC	24 VDC	5V DC
Shutter	Yes	No	No	Yes
