ｵｰｼｬﾝｲﾝｻｲﾄは､ｱﾌﾟﾘｹｰｼｮﾝの要件を対応する為に､頑丈で信頼性の高いﾀﾝｸﾞｽﾃﾝﾊﾛｹﾞﾝ光源を提供します｡ﾊｲﾊﾟﾜｰﾓﾃﾞﾙから長寿命ﾓﾃﾞﾙまで､当社のHL-2000製品ﾌｧﾐﾘｰは､360〜2400nmの測定に柔軟性を示します｡
全てのHL-2000ﾓﾃﾞﾙには､光源を冷却して安定させる為の統合ﾌｧﾝと､光を調整する為のﾌｨﾙﾀｰを収容する内蔵ﾎﾙﾀﾞｰが備えています｡一部のﾓﾃﾞﾙには､統合されたｼｬｯﾀｰと長寿命の電球があります｡ﾕﾆﾊﾞｰｻﾙ電源により､設定が迅速かつ簡単になります｡
|
Nominal Bulb Power |
4.75 W |
|
Source |
Long Lifetime Tungsten Halogen |
|
Typical Output Power |
4.7 mW |
|
Wavelength Range |
360nm - 2.4μm |
|
Drift of Optical Output |
<0.3% per hour |
|
Color Temperature |
2,800 K |
|
Source Lifetime |
10,000 hours (typical) |
|
Stability of Light Source Output |
0.15% peak-to-peak |
|
Warm-up Time |
10 minutes |
|
Safety & Regulatory |
CE, ROHS, WEEE |
|
Operating Humidity Specification |
5-95% without condensation at 40 °C |
|
Operating Temperature |
5 °C – 35 °C |
|
Fiber Connector |
SMA 905 |
|
Shutter |
NO |
|
Dimensions |
6.2 cm x 6 cm x 15 cm |
|
Integrated Cuvette Holder |
NO |
|
Integrated Filter Holder |
NO |
|
Power Consumption |
up to 15 W |
|
Power Requirements |
12 VDC |
|
Weight |
0.5 kg |
| HL-2000-LL | HL-2000-FHSA-LL | |
| Wavelength Range | 360nm - 2.4μm | 360nm - 2.4μm |
| Source | Long Lifetime Tungsten Halogen | Long Lifetime Tungsten Halogen |
| Nominal Bulb Power | 4.75 W | 4.75 W |
| Typical Output Power | 4.5 mW | 4.7 W |
| Shutter | No | Yes |
| Fiber Connector | SMA 905 | SMA 905 |
| Integrated Cuvette Holder | No | No |
