各分野で複数の特徴を持つｻﾝﾌﾟﾙを研究している場合でも､ﾗﾎﾞで数多くのｻﾝﾌﾟﾙを分析している場合でも､広いｽﾍﾟｸﾄﾙ範囲を網羅する光源を使用すると有益になります｡
重水素･ﾀﾝｸﾞｽﾃﾝﾊﾛｹﾞﾝ光源の組み合わせは､その要求に回答します｡有機物や小分子の測定から､ﾌﾟﾗｽﾁｯｸやﾎﾟﾘﾏｰの近赤外吸収まで､組み合わせ光源を使用すると､測定機能の拡張が可能になります｡2つのﾗﾝﾌﾟの組み合わせ又は広いｽﾍﾟｸﾄﾙ出力を持つ1つのﾗﾝﾌﾟを使用して､UV･可視･NIR範囲全体を調査できます｡
Engineering
|
Nominal Bulb Power |
25 W (deuterium), 20 W (tungsten halogen) |
|
Source |
Deuterium & Tungsten Halogen |
|
|
Typical Output Power |
194 µW (deuterium bulb), 615 µW (tungsten bulb) |
|
|
Wavelength Range |
230nm - 2.5μm |
|
|
Drift of Optical Output |
≤0.1%/hour @ 254 nm (deuterium), ≤0.1%/hour @ 700 nm (tungsten halogen) |
|
|
Source Lifetime |
1,000 hours |
|
|
Stability of Light Source Output |
≤0.1%/hour @ 254 nm (deuterium), ≤0.1%/hour @ 700 nm (tungsten halogen) |
|
|
Warm-up Time |
25 minutes |
|
Environmental:
|
Safety & Regulatory |
CE, ROHS, WEEE |
|
Operating Humidity Specification |
5-95% without condensation at 40 °C |
|
|
Operating Temperature |
5 °C – 35 °C |
|
Physical
|
Fiber Connector |
SMA 905 |
|
Shutter |
Yes |
|
|
Cuvette Pathlength |
10 mm |
|
|
Dimensions |
15 x 13.5 x 28.5 cm |
|
|
Integrated Cuvette Holder |
No |
|
|
Integrated Filter Holder |
No |
|
|
Power Consumption |
Approximately 78VA |
|
|
Power Requirements |
85-264 V 50/60 Hz |
|
|
Trigger/Shutter Input Connection |
SUB-D-15 pin |
|
|
Trigger/Shutter Input Signal |
TTL; Up to 2.5 Hz maximum |
|
|
Weight |
5.5 kg |
|
|
DH-2000-BAL |
DH-2000-FHS-DUV-TTL |
DH-2000-S-DUV-TTL |
|
Wavelength Range |
210nm - 2.5μm |
190nm - 2.5μm |
190nm - 2.5μm |
|
Source |
Deuterium & Tungsten Halogen |
Deep-UV Deuterium & Tungsten Halogen |
Deep-UV Deuterium & Tungsten Halogen |
|
Nominal Bulb Power |
25 W (deuterium) |
20 W (tungsten halogen) |
20 W (tungsten halogen) |
|
Typical Output Power |
194 µW (deuterium bulb) |
217 μW (deuterium) |
585 μW (deuterium) |
|
Source Lifetime |
1000 hours |
1000 hours |
1000 hours |
|
Stability of Light Source Output |
≤0.1%/hour @ 254 nm (deuterium) |
— |
— |
|
Warm-Up Time |
25 minutes |
25 minutes |
25 minutes |
|
Safety & Regulatory |
CE |
CE |
CE |
|
Operating Humidity Specification |
5-95% without condensation at 40 °C |
5-95% without condensation at 40 °C |
5-95% without condensation at 40 °C |
|
Operating Temperature |
5 °C – 35 °C |
5 °C – 35 °C |
5 °C – 35 °C |
|
Shutter |
Yes |
— |
Yes |
|
Fiber Connector |
SMA 905 |
SMA 905 |
SMA 905 |
|
Cuvette Pathlength |
— |
— |
— |
|
Dimensions |
15 x 13.5 x 28.5 cm |
15 x 13.5 x 28.5 cm |
15 x 13.5 x 28.5 cm |
|
Integrated Filter Holder |
No |
No |
No |
|
Power Consumption |
Approximately 78VA |
Approximately 78VA |
Approximately 78VA |
|
Trigger/Shutter Input Connection |
SUB-D-15 pin |
— |
SUB-D-15 pin |
|
Trigger/Shutter Input Signal |
TTL |
— |
TTL |
|
Weight |
5.5 kg |
5 kg |
5 kg |
|
Integrated Cuvette Holder |
No |
No |
No |
|
Power Requirements |
85-264 V 50/60 Hz |
85-264 V 50/60 Hz |
85-264 V 50/60 Hz |
